Reversible Plain Plug Gages

CLASS X TOLERANCE

Nominal SizeHandle Size
.0100 – .03001W
.0301 – .05001W
.0501 – .07501W
.0751 – .18002W
.1801 – .28103W
.2811 – .40604W
.4061 – .51005W
.5101 – .63506W
.6351 – .76007W
Nominal SizeHandle Size
.2540 – .76201W
.7645 – 1.2701W
1.2725 – 1.90501W
1.9075 – 4.57202W
4.5780 – 7.13743W
7.1399 – 10.31254W
10.3150 – 12.95405W
12.9565 – 16.12906W
16.1316 – 19.30407W

Class

XX, X, Y, Z

Features

  • All members 2” long
  • Class XXX – quoted upon request
  • Hard chrome & carbide quoted upon request
  • Unilateral tolerance furnished unless otherwise specified (go plus no go minus)
  • Chrome reversible plugs under .0350 are not available

Quantity prices apply to identical sizes.
