STI Thread Gage Manufacturer
R.H. FOR HELICAL COIL THREAD PLUG GAGE MEMBERS TAPERLOCK, FOR SCREW THREAD INSERT TYPE TAPPED HOLES
Inch
| Nominal Size | Handle Size |
|---|---|
| 2 – 56 | 00 |
| 2 – 64 | 00 |
| 3 – 48 | 00 |
| 3 – 56 | 00 |
| 4 – 40 | 00 |
| 4 – 48 | 00 |
| 5 – 40 | 0 |
| 6 – 32 | 0 |
| 6 – 40 | 0 |
| 8 – 32 | 0 |
| 8 – 36 | 0 |
| 10 – 24 | 0 |
| 10 – 32 | 0 |
| 12 – 24 | 1 |
| 1/4 – 20 | 1 |
| 1/4 – 28 | 1 |
| 5/16 – 18 | 2 |
| 5/16 – 24 | 1 |
| 3/8 – 16 | 2 |
| 3/8 – 24 | 2 |
| 7/16 – 14 | 3 |
| 7/16 – 20 | 3 |
| 1/2 – 13 | 3 |
| 1/2 – 20 | 3 |
| 9/16 – 12 | 3 |
| 9/16 – 18 | 3 |
| 5/8 – 11 | 3 |
| 5/8 – 18 | 3 |
| 3/4 – 10 | 4 |
| 3/4 – 16 | 3 |
What is STI Thread Gage?
STI gages are used to gage threads after tapping prior to insertion of Helical Coil Wire inserts. Gage Assembly makes STI gages in class 2B or class 3B.
Class
2B, 3B
