From standard applications to specialty uses, acme thread gauges are used for internal and external thread on products. Gage Assembly Company is a proud precision acme thread gauge manufacturer, producing high quality steel gauges that are designed to inspect threads on items with a wide variety of acme thread sizes, pitches, diameters and more. Our products are crafted to be lasting tools that can determine if your threaded component in tolerance.

Whether you’re interested in our in-stock catalog selection or need specialty acme thread gauges personalized to order, we have the right gauge for you.

View our stock and learn more about some of the finest gauges on the market.

General Purpose Acme Thread Gauges

Are you wondering how to use an acme thread gauge? The process starts by selecting the appropriate product. Customers can choose from acme thread ring gauge options or thread plug gauges. Consider an acme thread ring gauge set to inspect external parts, while checking internal threads with plug gauges. Both provide “GO and NOT GO” capabilities. “GO” thread rings allow external threaded parts to enter and “NOT GO” thread rings don’t. Likewise, “GO” plug gauges enter threaded parts while “NOT GO” plug gauges do not enter.

General purpose acme thread gauges are broken down into three fit classes (2G, 3G and 4G). Gage Assembly can manufacture an immense range of diameters up to 15.5-inch diameter.

What Makes Gage Assembly Unique

Since 1953, Gage Assembly Company has worked hard to provide customers with highly accurate, quality gauges at affordable prices. We are a family-owned, third-generation company and our employees take pride in the craftsmanship needed to produce top-quality acme thread gauges and numerous other gauge types.

Our products are offered at competitive prices and are made with some of the most durable materials on the market including:

  • Specialized steel – graphitic tool steel extends the life of acme thread gauges, along with temperature treatment.
  • Hard chrome plating – plating designed to wear over a longer period of time, no matter the conditions.
  • Root relief – thread flanks are ensured continued contact; accurate readings and gauge longevity are also sustained.

Learn more about our thread gauge manufacturing process.

As a precision acme thread gauge manufacturer, we ensure that every gauge is engineered and created to the highest standards in order to meet the needs of state-of-the-art technologies. Numerous industries, from national defense and aerospace to automotive, rely on our highly efficient gauges every day.

Additionally, we serve companies in the oil & gas industry to ensure safety, particularly during the tolerance inspection of valves, connected threaded fasteners and heavy load applications.

Contact Us Today

Turn to the experts in acme thread gauge manufacturing to find a precision gauge product that fulfills your industry requirements. Businesses large and small have chosen to work with Gage Assembly Company because of our 65 years of experience in the industry. We are also active members in the National Association of Manufacturers.

Contact us today for more information on our products and receive a quote.
