Master Setting Discs Gages
CLASS X TOLERANCE
| Nominal Size |
|---|
| .105 – .150 |
| .1501 – .2400 |
| .2401 – .365 |
| .365 – .510 |
| .5101 – .825 |
| .825 – 1.135 |
| 1.1351 – 1.510 |
| 1.5101 – 2.010 |
| 2.0101 – 2.510 |
| 2.5101 – 3.010 |
| 3.0101 – 3.510 |
| 3.5101 – 4.010 |
| 4.0101 – 4.510 |
| 4.5101 – 5.010 |
| Nominal Size |
|---|
| 2.67 – 3.81 |
| 3.8101 – 6.10 |
| 6.1001 – 9.27 |
| 9.2701 – 12.95 |
| 12.9501 – 20.96 |
| 20.9601 – 28.83 |
| 28.8301 – 38.35 |
| 38.3501 – 51.05 |
| 51.0501 – 63.75 |
| 63.7501 – 76.45 |
| 76.4501 – 89.15 |
| 89.1501 – 101.85 |
| 101.8501 – 114.55 |
| 114.5501 – 127.25 |
Class
XX, X, Y, Z
Style 1, 2 and 3 available
Features
- All tolerances are bilateral (50% plus 50% minus) except No. 2
- Hard chrome & carbide quoted upon request
- Class XXX – quoted upon request
